Product Details:
Place of Origin: China
Brand Name: Brightsail
Certification: CE ISO
Model Number: BSDF
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: Negotiable
Packaging Details: container
Delivery Time: 30-35 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 15 sets per month

Stainless Steel Iso Chili Grinding Machine Customized Large Capacity 100 To 1300kg Per Hr

Description
Warranty: One Year Capacity: 100-2000 Kg/h
Fineness: 10-120 Mesh Motor: 22-75kw
Discharge Motor: 0.75-1.5kw Blower: 7.5-18.5 Kw
Rotor Speed(rpm): 2700-3500 Package: Wooden Case And Container
Product Name: Chili Grinding Machine Other Name: Spice Grinding Machine
High Light:

iso chili grinding machine

,

100kg per hr chili grinding machine

,

1300kg per hr chilli powder machine

Stainless Steel Customized Large Capacity 100 To 1300 Kg Per Hr Chili Grinding Machine



The BSDF advanced hammer mill has a good grinding effect on various spices (such as pepper, turmeric, coriander seed, cinnamon, etc.), and of course it also has a good grinding effect on some other ingredients (such as chickpeas, cassava, tea, etc.) very good.

To grind spices, powder size can be 20~80 mesh;
To grind chickpea,cassava and some other food, powder size can be 20~150 mesh.


Technical data:

Model BSDF-350 BSDF-450 BSDF-550 BSDF-650 BSDF-750
Capacity(kg/h) 100-200 300-500 400-800 600-900 800-1300
Fineness(mesh) 20-120 20-120 20-120 20-120 20-120
Grind motor(kw) 22 37 45 55 75
Discharge motor(kw) 0.75 0.75 0.75 1.1 1.5
Blower(kw) 7.5 15 15 18.5 18.5
Rotor speed(rpm) 3500-4500 3300-4200 2900-3600 2400-3100 2100-2700


Working method:

The material enters the grinding cavity and passes through the high-speed rotation of three sets of knives one by one. The material is pulverized three times in a grinding chamber and then becomes a fine powder. Between the medium and fine grinding knife set and the fine grinding knife set, a device is designed to prevent coarse particles from entering the fine grinding area to ensure the fineness of the powder. The rotor speed is controlled by the frequency converter, and different granularities can be realized by adjusting the speed.



Main features:

1. No screen chamber or screen chamber is required. If you want to change the particle size of the powder, you only need to change the speed of the frequency converter.
2. There is almost no temperature rise in the grinding chamber, so there is no need to worry about the power being stuck in the screen or the product quality being affected.
3. If the raw materials are large or long (such as pepper, turmeric, cinnamon, etc.), the machine can be crushed directly. There is no need to make large 4. Save more power and its capacity is much higher than other traditional rolling mills with the same motor.
5. Grinding spices, herbs, grains,with excellent grinding effect.

How Can I Buy This Machine?
First of all, discuss all machines details and price with our sales person.
Secondly, confirm the price and payment terms Trade assurance/TT/Escrow/Western Union etc.
Thridy, send us purchased order and confirm our Proforma Invoice and arrange deposit. Once well received the deposit, we will arrange production.
At last, please arrange balance payment for us once machine is ready, then we will arrange shipment booking after received the balance payment and shipping the machine to you.
