Product Details:
|
| Product Name: | Spice Grinder,spice Grinding Machine,spice Pulverizer,spice Crusher Machine | Material: | SS304/316 |
|---|---|---|---|
| Capacity: | 20-1000 Kg/h | Feed Size: | 5-15 Mm |
| Output Size: | 60-700 Mesh | Medium: | Liquid Nitrogen |
| Temperature: | -196-0℃ | Motor: | 7.5-45kw |
| High Light: | flour making machine,powder grinding mill |
||
Fine fruit powder milling machine blueberry banana flour cryogenic pulverizer
BS cryogenic grinder is one of our latest products,liquid nitrogen was used as the cryogen energy to achieve high-quality grinding of materials at low temperature. It can be used for grinding of medicines, food and plastics of the field of high value-added at low temperature.
It can use microcomputer control unit for volume and the amount of nitrogen. Microcomputer is to set automatic level control system as to customer's requirement, operators just need to set the expected value of fineness, then the intelligent control system will automatically adjust the temperature, the refrigerant valve size, the discharge rate,etc based on the argument point by the host current,chamber pressure machine and pipe flow.
Working method:
Low temperature pulverizer system with liquid nitrogen as the cold source, the crushed material throughcooling embrittlement at low temperature easy to smash after entering the pulverizer cavity through the high-speed rotation of the impeller, the material and the leaf tooth plate, comprehensive effect between the material and the material are repeated impact, shear, collision, friction and so on, to reach the crushing effect. The crushed material is classified and collected by air classifier, and the material which does not reach the fineness requirement is returned to the silo to continue to smash, and most of the cold air is returned to the material bin for recycling.
Main features:
In the pulverizing system, the cold source forms a closed cycle system, which makes full use of energy and saves energy. The temperature of the cold source for grinding can be reduced to 196 degrees below zero. According to the brittle point temperature of the material, the temperature can be controlled in the grinding process, and the best grinding temperature can be selected, so as to reduce the energy consumption. The grinding fineness can reach 10-700 meshes, and even reach micron fineness. In addition, liquid nitrogen is used as grinding medium to achieve ultra-low temperature comminution, which can achieve the comprehensive effect of explosion proof and oxidation resistance of materials.
Our company:
Brightsail Machinery is a professional manufacturer & exporter for cryogenic grinder, spice grinding machine, mixing machine, drying machine, sifting machine and other food processing machine.
We take care of business, provide high-quality products and best service, we emphasize the internal management of enterprise and the advance of science and technology, and insist on the strategic policy of adapting ourselves to the market and participating in the competition, our products have been enjoying high reputation in over 50 countries around the world such as America, Gernmany, Canada, Indonesia, Pakistan, Saudi Arabia and so on.
We are willing to cooperate with friends of various circles at home and abroad. If you have any interest in our machine,please don't hesitate to contact us!
Technical data:
| Model | BS-200 | bs-500 |
| Grind motor(kw) | 7.5 | 45 |
| Input material size(mm) | 5-15 | |
| Medium | Liquid nitrogen | |
| Temperature(℃) | -196-0 | |
| Fineness(mesh) | 10-700(depends on materials) | |
| Capacity(kg/h) | 30-150(depends on materials) | 100-1000(depends on materials) |
| Grinding chamberØ(mm) | 180 | 500 |
| Feed and discharge | By screw feeder | |
