Product Details:
|
| Material: | SS304/316 | Volume: | 50-5000L |
|---|---|---|---|
| Warranty: | One Year | Mixing Time: | 4-10 Min |
| Power: | 1.1-11kw | Voltage: | Customized |
| High Light: | sugar powder making machine,flour hammer mill |
||
Milk food powder mixing machine coffee tea cocoa flour V shape mixer equipment
BSV powder mixing machine is applied to good liquidity dry powder and granular material mixing in pharmacy industry, chemical industry, food industry. This machine mixing cylinder structure special, efficiency is high, no blind angle,material adopt stainless steel, wall polishing treatment, nice appearance,equally mixing, can as per customer's request equip mixer, it can applied to fine powder material mixing.
Working method:
This machine is welded together by two V-type containers. The shape of the container is asymmetric with respect to the axis. Due to the rotating movement, the powder is continuously, alternately repeated, split, and run in the inclined cylinder. Material is randomly transferred from one area to another. The powder or granular micro-lips diffused in the space multiple times, repeatedly cutting, diffusing and mixing.
Main features:
1. Compact structure, operation simple, maintenance convenience.
2. The materials of tube adopts the stainless steel, both the inside wall and outside wall mirror polished, easy to wash, meet the GMP standard.
3. The machine adopts V form asymmetric material tube to compound, having no dead angle, no accumulation of materials, high speed, and short mixing time, high uniform mixing.
4. Circulate steady, have no noise.
5. If you want to set fixed mixing time and realize automatic stop, we can also make it for you.
Our company:
Brightsail Machinery is focus on the research of powder equipment, such as pulverizer machine, mixing machine, drying machine, sifting machine... etc. Our products can be applied in food, medicine, chemical and other industries and had won a good reputation. We have professional export office and professional engineer team. They will serve in the whole business. Same time after sales serve team can serve it if customer need on place.Most of machines are produced in our own factory ,thus we can offer you the best price and best technical service at the same time. We committed to providing high quality merchandise with good price.
Technical data:
| Model | BSV-100 | BSV-200 | BSV-300 | BSV-500 | BSV-1000 | BSV-1500 | BSV-2000 | BSV-2500 | BSV-300 | BSV-4000 |
| Total volume(m³) | 0.1 | 0.2 | 0.3 | 0.5 | 1.0 | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 |
| Mixing time(min) | 4-8 | 4-8 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 |
| Cylinder speed(rpm) | 15 | 15 | 12 | 12 | 12 | 10 | 10 | 8 | 8 | 7 |
| Main motor power(kw) | 1.1 | 1.1 | 1.1 | 2 | 4 | 5.5 | 7.5 | 7.5 | 7.5 | 11 |
| Agitator power(kw) | 0.75 | 0.75 | 0.75 | 1.5 | 2.2 | 2.2 | 3 | 3 | 4 | 5.5 |
| Weight(kg) | 230 | 290 | 400 | 550 | 850 | 1020 | 2040 | 2200 | 2500 | 2800 |
FAQ:
My friend, if you are interested in our V type powder mixer machine, could you tell me the following questions?
1. What's your mixing material?
2. What's the density of it?
3. What's capacity do you need for per batch? kg/batch or L/Batch?
4. What's the mixer's material do you need? Carbon steel, stainless steel304 or stainless steel316?
5. What's the voltage supply in your local place?
Please feel free to contact me.
