Product Details:
|
| Product Name: | Powder Granule Vacuum Feeder Feeding Conveying Machine | Application: | Food,chemical,pharmaceutical,etc |
|---|---|---|---|
| Usage: | Conveying Powder Or Granule | Capacity: | 400-6000kg/h |
| Motor: | 1.1-7.5kw | Material: | SS304/316 |
| Warranty: | One Year | Package: | Wooden Case Or Container |
| High Light: | powder conveying systems,powder screw conveyor |
||
Pneumatic chemical powder conveyor feeder systems protein flour vacuum conveyor
Our ZKS vacuum feeding machine is a new product, which was developed by our company on the basis of widely absorbing domestic and foreign similar products. Currently, it is the most advanced ,ideal and perfect vacuum conveying equipment of powder material, granular material, powder mixture. Vacuum charing machine can automatically transport a variety of materials to the hoppers of packaging machines, injection molding machine, grinder etc, also, it can convey mixed material directly to the mixer (such as V-type mixer, double cone mixer, zero gravity mixer etc.), thereby reducing the labor intensity of workers and solving the feeding problem when the powder spills etc.It is preferred equipment of the promotion of clean and civilized production which was chosen by the pharmaceutical factory, food factory through the "GMP" authentication.
Working method:
When the compressed air passes through the vacuum generator, the vacuum generator generates negative pressure to form a vacuum air flow, and the material is sucked into the nozzle and reaches the feeder chamber through the suction pipe. The filter completely separates the material from the air. When the chamber is full of material, the controller automatically cuts off the gas source and the vacuum generator stops working. At the same time, the warehouse door opens automatically, and the material falls into the equipment hopper. At the same time, the compressed air is automatically cleaned by the pulse backwash valve. When the time is up or the material level sensor sends a signal, the feeder automatically starts and reloads.
Main features:
1. The entire airtight transportation avoids flying dust and fundamentally eliminates external influences on materials.
2. Simple structure, easy to disassemble and clean.
3. The interior is smooth and has no dead corners and no material residues, which meets the national requirements for medicine, food and military industry.
4. Fewer moving parts, low operation, maintenance and maintenance costs.
5. High degree of automation, easy to form an automated production process with upstream and downstream equipment.
6. Beautiful and elegant, strong visual effect, has a good effect on improving the corporate image.
7. Low noise, small vibration and small impact on upstream and downstream equipment.
Our company:
Brightsail Machinery, China professional machine manufacturer, both the office and factory are located in Wuxi City. With 18 years mature experience of oversea market service, professional engineer for oversea machine installation and maintaining. Main machines all with CE certificates. Professional in machine solutions for powder grinding and mixing, as well as complete production lines. For the industry of food, chemical, medicine, plastics etc.. Provide extensive proposals to the oversea clients, from single machine to complete production lines. All machines can be customized.If you have any interest, please don't hesitate to contact us!
Technical data:
| Model | ZKS-1 | ZKS-2 | ZKS-3 | ZKS-4 | ZKS-6 | ZKS-7 | ZKS-20 |
| Motor(kw) | 1.1 | 2.2 | 3 | 5.5 | 5.5 | 7.5 | 11 |
| Capacity(kg/h) | 400 | 600 | 1200 | 2000 | 3000 | 4000 | 6000 |
| Remark:Conveying capacity is measured when pipe is 4 meter long and conveying material is flour.The longer the pipe is,capacity will drop.And capacity has great relationship with characteristic of materails. | |||||||
