800 Kg Per Hr Maximum Capacity Adjustable Fineness And Low Temperature Rise Ginger Milling Machines
Product Introduction Of Ginger Milling Machines:
BSP ginger processing machine is an advanced grinding machine with stable technical performance, low noise, low energy consumption, high efficiency, adjustable fineness and low temperature rise.
Our ginger crushing machine are perfect for sugar, food powder, herbs, spices, etc. . The unit is composed of crusher, powder collecting device, conveying pipe, electric control cabinet and so on. The crusher part is equipped with air grading equipment, so that the product particle size can be arbitrarily adjusted to prevent excessive crushing. The pulverized powder is conveyed to the cyclone under negative pressure and discharged by the discharge valve.
Working method Of Ginger Milling Machines:
The raw material is transported to the grinding chamber by the screw feeder and sheared by the eddy current and high frequency vibration generated by the high-speed cutting machine. Because of the negative pressure, the powder enters the main wheel. Through the rotation of the grading wheel and the centrifugal force of the air knife, the powder whose particle size is larger than the grading size is returned to the grinding chamber. Qualified powder will be discharged into the pipeline.
Main features Of Ginger Milling Machines:
1. Very fine powder manufacturing. In the food industry, materials can be ground to more than 300 mesh (such as rice and turmeric); in the chemical industry, materials can be ground to more than 1000 mesh. (such as talc)
2. When the mill is running, the particle size of powder can be controlled by frequency conversion without screening adjustment.
3. There is no dust in the production process, and the dust can be collected in the dust box.
Our service Of Ginger Milling Machines:
All products purchased in our company are guaranteed for one year. If there are any quality problems during the warranty period, our company will provide free warranty.
A. We'll test and adjust the machine and send it out. You can use it directly after you receive it.
B. Send operation video and instructions to customers to help them use the machine better.
In addition, our company also provides lifelong technical support and accessories. After sales service is not limited by time. We will solve this problem for you in time. If you have any questions about our products, please reply in time.
Technical data Of Ginger Milling Machines:
| Model | BSP-350 | BSP-450 | BSP-500 | BSP-750 |
| Input size(mm) | <15 | <15 | <15 | <15 |
| Fineness(mesh) | 60-2500 | 60-2500 | 60-2500 | 60-2500 |
| Capacity(kg/h) | 20-200 | 40-500 | 60-800 | 120-1800 |
| Crush motor(kw) | 11 | 18.5 | 30 | 55 |
| Grade motot(kw) | 1.5 | 4 | 5.5 | 11 |
| Blower(kw) | 7.5 | 11 | 18.5 | 37 |
| Feed motor(kw) | 0.55 | 0.55 | 0.75 | 1.5 |
| Discharge motor(kw) | 0.75 | 0.75 | 1.1 | 1.5 |
| Speed of principle axia(rpm) | -6500 | -5350 | -4600 | -3100 |
| Grading impeller speed(rpm) | 4000 | 4000 | 3500 | 3000 |
| Weight(kg) | 1600 | 1800 | 2300 | 3100 |
You can click this link below to know more about this ginger grinding machine.
Dry ginger grinding:https://youtu.be/5neTwhhKE80
Lesf grinding (about 200 mesh):https://youtu.be/9po1b5HLdTs
Turmeric grinding(about 200 mesh):https://youtu.be/WI-cz8sbBXo
We provide the complete set of equipment described in the above information! Each customer's process requirements will be different, we will be based on the specific requirements of the customer design system and give a quotation.
Welcome inquiry!
