Product Details:
|
| Product Name: | Sugar Powder Making Machine | Crusher Motor: | 5.5-30kw |
|---|---|---|---|
| Fineness: | 10-120 Mesh | Material: | SS304 |
| Suitable Materials: | Crystal Materials | Warranty: | 1year |
| Another Name: | Sugar Mill Machinery | Advantage: | Wide Application |
| High Light: | 5000kg/h sugar powder making machine,50kg/h sugar powder making machine,plc sugar powder making machine |
||
50 To 5000kg Per Hr Yield 12 To 120mesh Fineness Sugar Powder Making Machine
Production Of Sugar Powder Making Machine:
BSG icing sugar machine is a kind of high-efficiency sugar factory designed and developed by our company. This machine has a good grinding effect on crystal materials such as sugar, salt and baking soda. It is also suitable for grinding spices, herbs, grains, etc. There are two kinds of knives for you to choose from. One is the hammer type and the other is the disc type. The effect of disc grinding is slightly better than that of hammer grinding, that is, the effect of disc grinding is better than that of hammer grinding. The disc type generates heat more easily than the hammer type. When the material is highly heat sensitive, the hammer is the first choice.
Working Method Of Sugar Powder Making Machine:
The material is crushed by the high-speed relative motion of the moving fixed disk and the rotating disk, the impact of the trough disk, the friction of the material and the mutual impact. The crushed material can be discharged directly from the crushing chamber of the Crusher, and the required particle size can be obtained by installing screens with different pore sizes.
Main Features Of Sugar Powder Making Machine:
(1) The whole machine is made of stainless steel. After processing, the inner surface of the shell becomes smooth, which changes the residual powder phenomenon caused by the rough inner surface of the original machine. So that the production of drugs, food, chemical products more in line with national standards and GMP requirements.
(2) The grinding net is made of high quality stainless steel.
(3) All stainless steel structure, in line with GMP standards, in line with food grade, chemical grade, pharmaceutical grade standards.
Technical data Of Sugar Powder Making Machine:
| Model | BSG-300 | BSG-400 | BSG-500 | BSG-600 | BSG-700 |
| Speed of principal axis(rpm) | 5300 | 4800 | 3800 | 3300 | 2800 |
| Crusher motor(kw) | 5.5 | 7.5 | 15 | 22 | 30 |
| Blower(kw) | 4 | 5.5 | 7.5 | 11 | 15 |
| Discharge motor(kw) | 0.37 | 0.75 | 0.75 | 0.75 | 1.1 |
| Grinding capacity(kg/h) | 50-500 | 100-1000 | 300-1500 | 500-2500 | 1000-5000 |
We provide the complete set of equipment described in the above information! Each customer's process requirements will be different, we will according to the specific requirements of the customer design system and give a quotation.
