Product Details:
|
| Product Name: | Seeds Cake Pulverizing Machine | Material: | SS 304/316 |
|---|---|---|---|
| Application: | Food, Chemical, Medical,etc | Capacity: | 60-700 Kg/h |
| Fineness: | 40-1000 Mesh | Feed Size: | <15 Mm |
| Voltage: | Customized | Warranty: | One Year |
| Other Name: | Seeds Cake Grinding Mill | ||
| High Light: | 700kg/h powder milling machine,60kg/h powder milling machine,15mm powder milling machine |
||
60 To 700kg Per Hour Capacity With Two Grinding Discs Seeds Cake Pulverizing Machine
Description:seeds cake pulverizing machine
BSZ mill is specialized in processing various fruits, spices, walnuts, coffee beans, cocoa beans, rice and other food and chemical raw materials. The special milling machine for agricultural products, oils and chemical raw materials has imported foreign technology and has been continuously developed after many years of practice. This product meets food hygiene standards, is easy to operate, and has low noise. It is suitable for enterprises to process various food and chemical raw materials.
Technical data:seeds cake pulverizing machine
| Model | BSZ-350 | BSZ-450 | BSZ-550 |
| Capacity(kg/h) | 60-200 | 150-500 | 230-700 |
| Feed size(mm) | <15 | <15 | <15 |
| Output size(mesh) | 40-1000 | 40-1000 | 40-1000 |
| Cavity disc crush motor(kw) | 18.5 | 22 | 37 |
| Door disc crush motor(kw) | 15 | 18.5 | 30 |
| Feed screw motor(kw) | 0.37 | 0.55 | 0.75 |
| Speed(rpm) | 12000 | 9600 |
8400 |
Working method:seeds cake pulverizing machine
Two-way grinding wheel is rotated in opposite direction to improve grinding effect. Different diameter syringes are arranged on the disk wheels on both sides, and each section of the needle bar is arranged reasonably by three-dimensional simulation technology. It can effectively control the gap of the material in the pinhole and achieve the effect of cracking. Needle bar can be divided into hexagon, square, spear and so on. It has special effect on high melting point engineering plastics and room temperature ball milling.
Main features:seeds cake pulverizing machine
1.Sinple liner structure, easy to install and maintain.
2. It has two grinding plates that rotate on each other to achieve high speed rotation.
3. The grinding chamber does not need Sieving, and the particle size can be changed by changing the speed.
4. Can make very fine powder. Cocoa grinding cocoa, coffee, spices, dried fruit and other high sugar content or high oil content of materials, grinding effect is good.
Crushing effect:seeds cake pulverizing machine
