Product Details:
|
| MateriSUS304,SUS 316,carbon Steelal: | Customized | Volume: | 60-12000L |
|---|---|---|---|
| Warranty: | 1 Year | Package: | Wooden Case Or Container |
| Product Name: | Ribbon Blender | Other Name: | Powder Blender |
| Pre-sales Services: | Provided | ||
| High Light: | stainless steel 304 horizontal powder mixer,customized industrial horizontal powder mixer,180l volume horizontal powder mixer |
||
Industrial Stainless Steel Customized 60 To 12000L Volume Horizontal Powder Mixer
FAQ
Q: Where is your factory? How can I visit your factory?
A: Our factory is located In Wuxi province. We are warmly welcome you visit our Factory if you have a travel plan.
Q: How can I know your machine is designed for my product?
A: If you don't mind, you can send u sample and we test it on the machine. During that time, we will take video and clearer picture for you. If chance, we can take video online and show u.
Q: How can I trust you for the first time business?
A: Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba Trade Assurance service. It will protect your money during the whole stage of the transaction.
Q: How about the after service and guarantee period?
A: We make the guarantee time 12 months from the machine's arrival in buyer's facility and we have a professional team with an experienced technician to serve abroad and do the best after service to assure the machine whole life usage.
Q: How do we contact you?
A: Please leave a message and click "send" to send us an inquiry.
Description:
Horizontal ribbon mixer comprises of U-shape barrel,transmisstion parts and ribbon agitating blades which usually have doubleor triple layers with outside screw gathering material from side to center,and inside screw transmitting the material from center to sides to form convection mix.
Technical data:
| Model | Max work volume(L) | Speed(rpm) | Motor(kw) | Overall size(L*W*H)(mm) | Weight(kg) |
| BSR-100 | 60L | 62 | 3 | 1080*758*615 | 330 |
| BSR-300 | 180L | 49 | 5.5 | 1550*812*1015 | 780 |
| BSR-500 | 300L | 46 | 7.5 | 1975*1059*1120 | 955 |
| BSR-1000 | 600L | 35 | 11 | 2340*1380*1455 | 1400 |
| BSR-2000 | 1200L | 33 | 15 | 2480*1651*1805 | 2500 |
| BSR-3000 | 1800L | 33 | 18.5 | 2945*1896*1980 | 3300 |
| BSR-4000 | 2400L | 29 | 22 | 3038*1946*2205 | 3600 |
| BSR-5000 | 3000L | 29 | 30 | 3932*2010*2035 | 4320 |
| BSR-6000 | 3600L | 26 | 37 | 3938*1882*2246 | 5300 |
| BSR-8000 | 4800L | 26 | 45 | 3986*2160*2516 | 6800 |
| BSR-10000 | 6000L | 19 | 55 | 4500*2270*2667 | 8900 |
| BSR-15000 | 9000L | 17 | 75 | 5363*2470*3020 | 9950 |
| BSR-20000 | 12000L | 17 | 90 | 5670*2650*3497 | 11140 |
Working Method:
BSR series ribbon mixer is mainly composed of mixing barrel, spiral ribbon and driven parts. The spiral ribbon consists of two layers. That is, the inner belt makes the material move outward, and the outer belt makes the material move inward, forming a good material circulation. The circular motion of the ribbon enables the mixer to achieve good mixing efficiency in a very short time.
If you are looking for dry powder mixer, such as spice powder mixer, protein powder mixer, spice powder mixer, our BSR ribbon mixer is a very good choice.
1. Under the feasibility factor, the mixing effect of the horizontal belt mixer is not affected by the particle size and density, and it also has a good mixing effect on the viscous material.
2. Smooth mixing process to reduce the damage of fragile materials, flying knife structure in the crusher also played a role.
3. Horizontal structure, low height, easy installation.
4. In the mixing structure, the forward and reverse rotating screw rods are installed on the same horizontal axis to form a low-power and high-efficiency mixing environment.
Please contact us if you have interests in our products.
