Product Details:
|
| Product Name: | Grain Powder Mill Grinder Milling Making Machine Air Classifier Mill | Material: | SS 304/316 |
|---|---|---|---|
| Capacity: | 20-1800 Kg/h | Input Size: | <15 Mm |
| Fineness: | 60-2500 Mesh | Crusher Motor: | 11-75 Kw |
| Voltage: | Customized | Package: | Wooden Case Or Container |
| High Light: | flour blending machine,plantain grinder machine |
||
Fine rice husk grain powder making machine cereal chickpeas grinder machine
BSP ultra-fine pulverizer is developed and optimized based on the similar domestic and foreign products with our practical experience, this multifunction equipment is very suitable for grinding and classifying materials in food, chemical, pharmaceutics and other fields.For example: spice, herbs, grains, sugar, salt, chemical materials, etc.
It is one of the most popular products in our company, many customers purchased this kind of machine for making fine powder, such as America, Spain, Portugal, Poland, Thailand, Pakistan, Myanmar, etc. And they're very satisfied with our machine.
Working method:
Material is cut and crushed by high-speed rotating blade through screw conveyor. Material is transported into cyclone separator by negative pressure air transportation, and material is discharged. Dust is filtered and recovered by vacuum box through bag or filter barrel. No dust is flying in the production process.
Main features:
1. The grinder is integrated with the classifier, and there is no over-grinding.
2. Sharp particle size distribution, fineness 60-2500 mesh adjustable.
3. The internal temperature is cooled by airflow, and the grinder room is cooled by a water-cooled jacket, which is suitable for heat-sensitive materials.
4. No dust pollution in negative operation.
5. Compact structure and easy installation.
6. Fewer wearing parts, easy maintenance.
Our service:
A. Technical service
1.We calculate the capacity and recommend the best models.
2.We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.
3.We supply the spare parts and technical support in & after the warranty time.
4.We supply the training course to your workers at our factory if you need.
B. After-sales service
1. Technical support for your installation, operation and maintenance.
2. One year’s warranty, and you can pay for extended warranty.
3. Spare parts and technical support at most economic prices after the warranty.
Technical data:
| Model | BSP-350 | BSP-450 | BSP-500 | BSP-750 |
| Input size(mm) | <15 | <15 | <15 | <15 |
| Fineness(mesh) | 60-2500 | 60-2500 | 60-2500 | 60-2500 |
| Capacity(kg/h) | 20-200 | 40-500 | 60-800 | 120-1800 |
| Crush motor(kw) | 11 | 18.5 | 30 | 55 |
| Grade motot(kw) | 1.5 | 4 | 5.5 | 11 |
| Blower(kw) | 7.5 | 11 | 18.5 | 37 |
| Feed motor(kw) | 0.55 | 0.55 | 0.75 | 1.5 |
| Discharge motor(kw) | 0.75 | 0.75 | 1.1 | 1.5 |
| Speed of principle axia(rpm) | -6500 | -5350 | -4600 | -3100 |
| Grading impeller speed(rpm) | 4000 | 4000 | 3500 | 3000 |
| Weight(kg) | 1600 | 1800 | 2300 | 3100 |
