Masala Powder Grinder Machine for Cinnamon Red Pepper Coriander Seeds stable

Masala Powder Grinder Machine for Cinnamon Red Pepper Coriander Seeds stable
Masala Powder Grinder Machine for Cinnamon Red Pepper Coriander Seeds stable Masala Powder Grinder Machine for Cinnamon Red Pepper Coriander Seeds stable

Large Image :  Masala Powder Grinder Machine for Cinnamon Red Pepper Coriander Seeds stable

Product Details:
Place of Origin: China
Brand Name: Brightsail
Certification: CE ISO
Model Number: BSDF
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: Negotiable
Packaging Details: container
Delivery Time: 30-35 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 15 sets per month

Masala Powder Grinder Machine for Cinnamon Red Pepper Coriander Seeds stable

Description
Warranty: One Year Capacity: 100-2000 Kg/h
Fineness: 10-120 Mesh Motor: 22-75kw
Discharge Motor: 0.75-1.5kw Blower: 7.5-18.5 Kw
Voltage: Customized Package: Container
High Light:

ultra fine powder grinder

,

industrial powder grinder

Masala powder grinder machine cinnamon red pepper coriander seeds pulverizer

BSDF advanced hammer mill consists of main motor, auxiliary motor, and electrical control cabinet with the capabilities of winnowing, non-sieve or mesh, equality of granule size, and continuous processing etc.
Material is sent to mill chamber to be crushed, by force of blower, powder will go to cyclone and be discharged, the ultra-fine powder will be separated to dust collecting box.Designed according to GMP standard and wholly made of stainless steel, this machine has no flying dust during production, and can improve the utilization rate of material and reduce the cost of enterprise.



Working method:

The material enters the crusher cavity from the feeding port, and the material passes through the high-speed rotating, coarse, medium and fine crushing knife set in turn. When passing through the coarse crushing knife group, the material is initially crushed, and then enters the middle crushing knife group, the material is further crushed, and finally passes through the fine crushing knife group to obtain the final product.
A device for separating excessive coarse material particles is arranged between the medium crushing and fine crushing knife groups to control the excessive coarse particles entering the fine crushing knife groups, thereby ensuring the discharge fineness. The cutter head speed is controlled by a frequency converter. The cutter head speed can be adjusted according to product requirements to obtain products with different granularities. There is no screen in the crusher head, and the heat generation is low. The feed particles generally do not need coarse crushing, and the output is large.



Our company:

Brightsail Machinery Co.,Ltd. is the trade department of Jiangyin Heng Sheng Steel Structure Co.Ltd which is established in 2002. It's professional and engaged in research, development, production,sale and service of grinder machine, mixer, sifting machine, overall powder solution, welding service, metal processing and chemical powder. In addition,we have abtained CE,ISO certificates.
In 2018, our company obtained prize from Alibaba group as top100 seller in east China region. Our products have been exported to such contrires and regions as USA, Canada, Germany, Australia, Europe, Africa, South Asia, middle Asia. We also welome OEM and ODM models. Our company name “Brightsail” is also our hope to all of our customers and parters around the world, we hope will grow together and set a sail to bright.



FAQ:

If you want to send inquriy about this kind of machine, could you please tell me some details as below?
1) What material you want to grind, is it dry? what is the size of feed material?
2) What capacity you expect ? (kg/h)
3) What mesh or mm or micron(size) of the powder you want?
4 ) What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p;
(This machine we only provide industrial voltage, because it is for industrial use,not for family.)
5) Usually we use stainless steel 304, if you want stainless steel 316, it's OK and please tell us.


Technical data:

Model BSDF-350 BSDF-450 BSDF-550 BSDF-650 BSDF-750
Capacity(kg/h) 100-200 300-500 400-800 600-900 800-1300
Fineness(mesh) 20-120 20-120 20-120 20-120 20-120
Grind motor(kw) 22 37 45 55 75
Discharge motor(kw) 0.75 0.75 0.75 1.1 1.5
Blower(kw) 7.5 15 15 18.5 18.5
Rotor speed(rpm) 3500-4500 3300-4200 2900-3600 2400-3100 2100-2700
