Product Details:
|
| Product Name: | Grain Powder Mill Grinder Milling Making Machine Air Classifier Mill | Material: | SS 304/316 |
|---|---|---|---|
| Capacity: | 20-1800kg/h | Input Size: | <15 Mm |
| Fineness: | 60-2500 Mesh | Crusher Motor: | 11-75 Kw |
| Voltage: | Customized | Package: | Wooden Case Or Container |
| High Light: | Wheat Flour Pulverizer Machine,Rice Husk Pulverizer Machine |
||
200mesh fine grain powder grinder wheat flour rice husk pulverizer machine
BSP ultra-fine pulverizer is is a high-energy vertical grinding mill incorporating an internal air classifying wheel to controll product particle size distribution, which has been widely used for milling/pulverizing high fiber content materials, heat sensitive materials and brittle materials in food, chemical and pharmaceutical industry.
Application:
1.Grains: rice, wheat, sorghum, pigeon pea, chickpea, oat, millet, barley,etc.
2.Spice: turmeric, ginger, garlic, onion, cinnamon, black pepper, fennel, etc.
3.Herbs: tea leaf, moringa leaf, Chinese herb, ginseng, mulberry leaf, barley grass, flower, etc.
4.Crystal materials: icing sugar, baking soda, salt, MSG, etc.
5.Chemical products: carbonate, zinc stearate, resin, rubber, etc.
6.Pharmacy products: vitamin powder, protein powder, Western medicine, etc.
Working method:
Material would be conveyed by feeding system evenly to milling chamber, and would be impacted by highspeed rotating beater, and also under the centrifugal force, it would impact the grinding track. By several different pulverization powers, the material would be milled into fine powder. The milled powder would go with air flow up to the classifying chamber. Withthe help of adjustable classifier wheel, coarse powder and fine powder would be separated. Qualified fine powder would go through the wheel vane then into the cyclone separator or dust collector, while mixture of coarse powder and fine powder would fall down to the milling chamber to be milled again.
Main features:
1. Alloy steel hammer blades and rotor
2. GMP and food grade design
3. Negative working condition can prevent dust and be suitable for heat sensitive material pulverization.
4. Output size is adjustable via air classifier and air flow rate.
5. Feeding rate is automatic controlled
6. Particle size distribution can be accurately controlled
Technical data:
| Model | BSP-350 | BSP-450 | BSP-500 | BSP-750 |
| Input size(mm) | <15 | <15 | <15 | <15 |
| Fineness(mesh) | 60-2500 | 60-2500 | 60-2500 | 60-2500 |
| Capacity(kg/h) | 20-200 | 40-500 | 60-800 | 120-1800 |
| Crush motor(kw) | 11 | 18.5 | 30 | 55 |
| Grade motot(kw) | 1.5 | 4 | 5.5 | 11 |
| Blower(kw) | 7.5 | 11 | 18.5 | 37 |
| Feed motor(kw) | 0.55 | 0.55 | 0.75 | 1.5 |
| Discharge motor(kw) | 0.75 | 0.75 | 1.1 | 1.5 |
| Speed of principle axia(rpm) | -6500 | -5350 | -4600 | -3100 |
| Grading impeller speed(rpm) | 4000 | 4000 | 3500 | 3000 |
| Weight(kg) | 1600 | 1800 | 2300 | 3100 |
