12000l Volume 17-62rpm Powder Ribbon Blender

12000l Volume 17-62rpm Powder Ribbon Blender
12000l Volume 17-62rpm Powder Ribbon Blender
12000l Volume 17-62rpm Powder Ribbon Blender 12000l Volume 17-62rpm Powder Ribbon Blender 12000l Volume 17-62rpm Powder Ribbon Blender 12000l Volume 17-62rpm Powder Ribbon Blender

Large Image :  12000l Volume 17-62rpm Powder Ribbon Blender

Product Details:
Place of Origin: China
Brand Name: Brightsail
Certification: CE ISO
Model Number: BSR
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: Negotiable
Packaging Details: Wooden case or container
Delivery Time: 30-35 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10 sets per month

12000l Volume 17-62rpm Powder Ribbon Blender

Description
Product Name: Whey Protein Powder Ribbon Blender Application: Food,chemical,pharmaceutical,etc
Speed(rpm): 17-62 Applicable Materials: Dry Powder,granules
Material: SUS304,SUS 316,carbon Steel Volume: 50-20000L
Other Name: Whey Protein Flour Mixer Machine Another Name: Whey Protein Powder Ribbon Mixer
High Light:

12000l volume powder ribbon blender

,

62rpm powder ribbon blender

,

17rpm ribbon blender for powder mixing

12000L Work Volume Powder Spraying Liquid Mixer Whey Protein Powder Ribbon Blender



BSR powder batch mixer comprises of U-shape barrel, transmisstion parts and ribbon agitating blades which usually have double or triple layers with outside screw gathering material from side to center and inside screw transmitting the material from center to sides to form convection mix.

The powder batch mixer is widely used in solid-solid (powder material) and solid-liquid(powder material-fluidity material) mixing in the fields of chemical industry, pharmacy, foodstuff industries.



Technical data:whey protein powder ribbon blender

Model Max work volume(L) Speed(rpm) Motor(kw) Overall size(L*W*H)(mm) Weight(kg)
BSR-100 60L 62 3 1080*758*615 330
BSR-300 180L 49 5.5 1550*812*1015 780
BSR-500 300L 46 7.5 1975*1059*1120 955
BSR-1000 600L 35 11 2340*1380*1455 1400
BSR-2000 1200L 33 15 2480*1651*1805 2500
BSR-3000 1800L 33 18.5 2945*1896*1980 3300
BSR-4000 2400L 29 22 3038*1946*2205 3600
BSR-5000 3000L 29 30 3932*2010*2035 4320
BSR-6000 3600L 26 37 3938*1882*2246 5300
BSR-8000 4800L 26 45 3986*2160*2516 6800
BSR-10000 6000L 19 55 4500*2270*2667 8900
BSR-15000 9000L 17 75 5363*2470*3020 9950
BSR-20000 12000L 17 90 5670*2650*3497 11140



Working method:whey protein powder ribbon blender

The patented technology of the utility model drives the material in the barrel to rotate through the inner diameter and outer diameter screws installed on the mixing shaft, so that the mixer can rotate the animals in the barrel to the greatest extent. In the agitator structure, the spiral is designed as an internal and external reverse spiral and a left to right reverse spiral. When the agitator works, the inner screw carries animal materials and rotates near the shaft to push both sides of the shaft. Axial rotation generates axial thrust from both sides to make the materials convection, shear and mix in the pipeline, so that the materials can be mixed quickly and evenly in a short time.





Main features:whey protein powder ribbon blender

1. Simple structure in horizontal U shape, easy in installation and maintenance.

2.  Adopting advanced world famous brand components in pneumatic parts, motor, electric parts, bearings and operation parts.

3. Hermetic seals are adopted on both sides of ribbon mixer.
4. Cover has a safety net.
5. Pneumatic valve is adopted to discharge material.



12000l Volume 17-62rpm Powder Ribbon Blender 0

Detailed Images:
whey protein powder ribbon blender

12000l Volume 17-62rpm Powder Ribbon Blender 1

(1) Safety net: There is a safety net on the cover, so that operator cannot reach out arms into the mixer, danger can be prevented.

(2) Ribbon inside the mixer: make the mixing effect better.



12000l Volume 17-62rpm Powder Ribbon Blender 2

(1) Discharge part: Pneumatic valve is adopted to discharge material. Mixing dry powder or powder with a little liquid are applicable.

(2) Two types of sealing: The packing seal is a conventional seal on which the gas seal can be added to increase the sealability. The mechanical seal has better sealing performance than the packing seal, less leakage and long service life. It can be used for powder and liquid, and has a wider range of use and higher price.
