Product Details:
|
| Product Name: | Oyster Shell Crushing Machine | Capacity: | 100-2000 Kg/h |
|---|---|---|---|
| Fineness: | 10-120 Mesh | Motor: | 22-75kw |
| Discharge Motor: | 0.75-1.5kw | Sdvantage: | Large Capacity |
| Other Name: | Oyster Shell Mill | Another Name: | Oyster Shell Pulverizer |
| High Light: | 100kg/h oyster shell crushing machine,120 mesh oyster shell crushing machine,1300kg/h oyster shell crusher |
||
Hot Selling Large Capacity 100 To 1300kg Per Hour Oyster Shell Crushing Machine
BSDF seaweed processing plant can crush all kinds of food powder and granular raw materials. Steel plate welding structure is adopted. The motor and hammer mill are installed on the same base. Triangular tape is used for transmission. The rotor can do positive and negative work after dynamic balance test. The feed hole is at the top of the hammer mill. The hammer pieces are arranged symmetrically. The machine has the advantages of reasonable structure, durability, safety and reliability, convenient installation, convenient operation, small vibration and high grinding efficiency.
Working method:oyster shell crushing machine
The materials to be crushed are fed from the feeding port, sucked into the coarse crushing area through the negative pressure of the fan for coarse crushing, and the large particles after coarse crushing enter the medium crushing area for secondary crushing. After secondary crushing, the particles are separated from each other by the grading wheel, and the particles meeting the requirements of fine crushing enter the fine crushing area for crushing. Large particles that do not meet the requirements of the fine crushing area will remain in the medium crushing area for re crushing. With the help of the fan wheel, the powdery powder in the fine crushing area is discharged from the crushing chamber through the negative pressure air flow of the fan through the discharge port, and then enters the cyclone separator. The finished product is discharged by itself through the electric rotary valve at the bottom of the separator. The dusty gas enters the dust removal box, the dust is blocked in the dust removal box by the cloth bag in the dust removal box, and the clean gas is discharged from the fan outlet.
Main features:oyster shell crushing machine
1) Mills don't need sieves or sieves! Change the size of the powder by changing the speed.
2) Because there is no screen in the mill, there is no heat rise in the mill.
3) If the power supply is stuck on the screen or the rolling mill heats up and affects the product quality, don't worry. This is why it is ideal for grinding heat sensitive materials or materials containing fiber or oil.
4) The crusher part combines the coarse mill, medium mill and fine mill to directly manufacture fine powder from large raw materials, which is very effective.
5) Compared with the traditional rolling mill with similar motors, it saves more power and has greater production capacity.
Technical data:oyster shell crushing machine
| Model | BSDF-350 | BSDF-450 | BSDF-550 | BSDF-650 | BSDF-750 |
| Capacity(kg/h) | 100-200 | 300-500 | 400-800 | 600-900 | 800-1300 |
| Fineness(mesh) | 20-120 | 20-120 | 20-120 | 20-120 | 20-120 |
| Grind motor(kw) | 22 | 37 | 45 | 55 | 75 |
| Discharge motor(kw) | 0.75 | 0.75 | 0.75 | 1.1 | 1.5 |
| Blower(kw) | 7.5 | 15 | 15 | 18.5 | 18.5 |
| Rotor speed(rpm) | 3500-4500 | 3300-4200 | 2900-3600 | 2400-3100 | 2100-2700 |
