Product Details:
|
| Product Name: | Radix Liquiritiae Mill Grinding | Applicated Fields: | Foodstuff Industry,chemical Industry,medical Industry |
|---|---|---|---|
| Warranty: | One Year | Capacity: | 3-300 Kg/h |
| Fineness: | 10-120 Mesh | Feed Size: | <10mm |
| Other Name: | Glycyrrhiza Crushing Machine | ||
| High Light: | 10mm herbal powder machine,radix herbal powder machine,liquiritiae mill powder grinding machine |
||
High Rotary Grinding Speed 3 To 300 Kg Per Hr Capacity Radix Liquiritiae Mill Grinding
BS high-speed hammer mill is mainly used for crushing chemical raw materials, Chinese medicinal materials containing wood roots, leaves, low-oil grains, and hard and brittle materials such as ginger, chili, chickpeas, moringa leaves, dried flowers, etc.
Technical Data:
| Model | BS-180 | BS-250 | BS-300 | BS-350 |
| Feed size(mm) |
<10mm(granule) <15*40*2(leaf) |
<10mm(granule) <15*40*2(leaf) |
<10mm(granule) <15*40*2(leaf) |
<10mm(granule) <15*40*2(leaf) |
| Grind fineness(mesh) | 10-120 | 10-120 | 10-120 | 10-120 |
| Capacity(kg/h) | 3-50 | 10-100 | 20-200 | 30-300 |
| Grind chamber diameter(mm) | 200 | 270 | 330 | 380 |
| Rotor speed(rpm) | 5900/8600 | 4200/6200 | 2600/5100 | 2200/4400 |
| Motor(kw) | 2.2 | 5.5 | 7.5 | 11 |
| Overall size(L*W*H)(mm) | 840*470*1020 | 930*600*1200 | 1000*650*1500 | 1150*700*1600 |
| Weight(kg) | 112 | 210 | 296 | 430 |
Working Method:
The crushed material can be discharged directly from the mill. There is a movable blade on the spindle. A fixed gear ring is arranged in the grinding cavity. Under the ring gear, there’s a screen. When the spindle is working at high speed, the movable cutter head is running together. The material is impacted, rubbed and cut by fixed tooth ring and movable hammer. Matter also collides with each other. Together, they are compressed into a powder.
Main Features:
1. The machine is easy to crush the target materials, the size of flour can be achieved by changing the screen Mesh.
2. The utility model has the characteristics of stable operation and high efficiency.
3. The crushed material is discharged directly from the grinding room of the main engine.
4. The whole machine is made of stainless steel with smooth inner wall to avoid the accumulation of power in the inner wall.
5. The machine produces medicine, chemical, food and other products in line with national requirements, in line with GMP standards.
