Product Details:
|
| Output (kg/h): | 100 - 4000 Kg/h | Feeding Size (mm): | 0 - 15 Mm |
|---|---|---|---|
| Output Size (mesh): | 60 - 2500 Mesh | Power (kW): | 12.12 |
| Range Of Spindle Speed(r.p.m): | 580 - 2900 R.p.m | Material: | SUS304, SUS316, Other, SUS304 |
| Condition: | New | Type: | Pulverizer |
| Voltage: | Customized | Dimension(L*W*H): | Customizable |
| Weight (KG): | 1500 KG | Warranty: | 1 Year |
| Key Selling Points: | Automatic | Applicable Industries: | Building Material Shops, Food & Beverage Factory, Farms, Retail, Food Shop, Food & Beverage Shops, Other |
| Showroom Location: | None | Marketing Type: | Hot Product 2023 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Bearing, Motor |
| MOQ: | 1 Set | Other Name: | Hammer Mill |
| Advantage: | High Effieciency | Fineness: | 60-2500 Mesh |
| Name: | Chinese Herbal Medicine Powder Making Machine | Package: | Wooden Case |
| Feature: | High Efficiency Easy Operation | Port: | SHANGHAI |
Main application of our BSK jet mill
- Abrasive products
- Sticky products
- Mineral fillers
- Ceramic fillers
- Food
- Chemical products
- Agricultural chemicals
Flow Chart of our air jet mill machine micronizer
Working method of our air jet mill machine
Air Jet Mill is a pulverizing machine which uses high-speed compressed air to grind dry-type materials into ultra fine powders.
The main part consists of screw feeder, milling nozzle, milling chamber, classifier chamber, and etc.
In adjustable speed, screw feeder doses the raw materials stably and continuously into the jet mill. Compressed air reaches a very high speed when rushing through the special designed nozzles.
Carried by the compressed air, materials crash in the midst of air flow, where they grind with each other by impacting repeatedly.
The ground materials fly upwards with the rising air, entering the classifier chamber, where ground materials facing two forces the centrifugal force result from the fast rotation of classifier wheel and the pneumatic attraction by the suction fan.
If the ground materials are finer than grading range, pneumatic attraction is stronger, so materials pass through the classifier wheel and move on to the cyclone and dust collector to be collected. In contrast, coarser materials are rejected back to the milling chamber to be re-milled.
| Model | BSK-100 | BSK-200 | BSK-300 | BSK-400 | BSK-600 | BSK-800 |
| capacity(kg/h) | 0.5-10 | 10-100 | 80-200 | 100-500 | 200-700 | 400-1500 |
| Air consumption(m³/min) | 3 | 4.5 | 6 | 10 | 20 | 40 |
| Working pressure(Mpa) | 0.75-0.85 | 0.75-0.85 | 0.75-0.85 | 0.75-0.85 | 0.75-0.85 | 0.75-0.85 |
| Feed diameter | ≥60 | ≥60 | ≥60 | ≥60 | ≥60 | ≥60 |
| Grinding fineness(um) | 0.5-30 | 0.5-30 | 0.5-30 | 0.5-30 | 0.5-30 | 0.5-30 |
| Energy Consumption Power(kw) | 20 | 40 | 95 | 95 | 188 | 380 |
Company information
We Brightsail Machinery are engaged in manufacturing a wide range of grinders and mixers.
Our machine can be used in food plant plant and chemical plant for powder making or powder mixing. And we are devoted to offering customization service to our clients to meet various requirements. Within years, we have exported machines to North American, European and Asian countries.
Till 2023 year, we have exported machines to more than 85 countries.
