Product Details:
|
| Motor Power（kw）: | 1.5-18.5 | Processing Fineness（um）: | 2-40 |
|---|---|---|---|
| Motor Speed（r/min）: | 2900 | Cooling Water Pipe(mm): | 10-12 |
| Grinding Disc Diameter(mm): | 50-200 | Finished Product: | Peanut Butter,tahini,Sesame Paste |
| Another Name: | Sesame Grinding Machine | Function: | Grinding |
| High Light: | 1.5kw sesame grinder,peanut butter making machine 1.5kw,40um sesame grinder |
||
60 - 400kg Weight Peanut Butter making machine sesame grinder machine
Product Introduction:
The colloid mill for sale is a machine for fine processing of fluid material, with superior ultra-fine crushing, dispersion emulsification, homogenization, mixing and other effects. the material particle size can reach from 2-50 microns after processing with this machine, and the degree of homogeneity is more than 90%, which is ultrafine ideal equipment for processing.
This colloid mill is suitable for ultrafine crushing of wet material (pharmaceuticals, food area, chemical area and other industries). It has the big advantages in crushing, emulsifying, homogenizing, and mixing for material.
Technical Data:Peanut Butter making machine sesame grinder machine
| Model |
Motor power (kw) |
Motor speed (r/min) |
Processing fineness (um) |
Capacity | Grinding disc diameter | Cooling water pipe | Outlet | Inlet | Weight |
Boundary dimension (L*W*H) |
| (t/h) | (mm) | (mm) | (mm) | (mm) | (kg) | (mm) | ||||
| BSQT-F50 | 1.5 | 2900 | 2-40 | 0.01-0.1 | 50 | 10 | 20 | 30 | 60 | 255*500*700 |
| BSQT-F65 | 1.5/2.2 | 2900 | 2-40 | 0.02-0.5 | 65 | 10 | 20 | 30 | 65 | 500*345*675 |
| BSQT-F80 | 3 | 2900 | 2-40 | 0.3-1 | 80 | 12 | 25 | 48 | 150 | 700*570*920 |
| BSQT-F100 | 5.5 | 2900 | 2-40 | 0.5-2 | 100 | 12 | 25 | 66 | 240 | 800*645*900 |
| BSQT-F120 | 7.5 | 2900 | 2-40 | 0.5-3 | 120 | 12 | 32 | 66 | 250 | 800*645*900 |
| BSQT-F140 | 11 | 2900 | 2-40 | 0.5-4 | 140 | 12 | 32 | 66 | 275 | 800*750*1020 |
| BSQT-F200 | 18.5 | 2900 | 2-40 | 1-10 | 200 | 12 | 38 | 100 | 400 | 900*850*1200 |
Working Method :Peanut Butter making machine sesame grinder machine
This machine is based on the relative motion of the stator and rotor of different geometric shapes under high-speed rotation. When the processed material passes through the adjustable stator and rotor gap under the action of its own weight, air pressure and centrifugal force, it receives a strong shear force , Friction, impact, high frequency vibration and other composite forces are effectively broken, dispersed, emulsified and mixed to obtain the ideal product.
The crushing room is equipped with three grinding areas, the first level is the coarse grinding area, the second level is the fine grinding area, and the third level is the ultrafine grinding area. By adjusting the gap between the stator and the rotor, the required super Micro-crushing effect (can also be recycled).
Peanut Butter making machine sesame grinder machine
Detailed Pictures:
Peanut Butter making machine sesame grinder machinePeanut Butter making machine sesame grinder machine
