Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine

Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine
Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine
Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine

Large Image :  Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine

Product Details:
Place of Origin: China
Brand Name: Brightsail
Certification: CE ISO
Model Number: BSQT-F
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: Negotiable
Packaging Details: Container
Delivery Time: 5-8 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 sets per month

Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine

Description
Motor Power(kw): 1.5-18.5 Processing Fineness(um): 2-40
Motor Speed(r/min): 2900 Cooling Water Pipe(mm): 10-12
Grinding Disc Diameter(mm): 50-200 Finished Product: Peanut Butter,sesame Paste
Another Name: Sesame Grinding Machine Function: Grinding
High Light:

Colloid Mill Grinding Machine

,

Industrial 40um Peanut Butter Grinding Machine

,

Chili Paste Grinding Machine

Industrial 2 To 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine



Why Choose Us:​
Within years, we have exported machine to over 70 countries.

For example, New Zealand, Germany, Poland, Thailand, Pakistan, Qatar, Nigeria and many other countries.

So you do not need to worry about the export procedures because we know all the procedures.



Product Introduction:

The colloid mill for making chili paste is a machine for fine processing of fluid materials, which has excellent superfine grinding, dispersing and emulsification, homogenizing, mixing and other effects. The particle size of the material processed by this machine can reach 2-50 microns, and the uniformity is more than 90%. It is an ideal equipment for ultra-fine processing.
It is suitable for superfine grinding of wet materials in pharmaceutical, food, chemical and other industries. It has great advantages in crushing, emulsification, homogenization and mixing of materials.



Technical Data:

Model

Motor power

(kw)

Motor speed

(r/min)

Processing fineness(um)

Capacity

Grinding disc diameter Cooling water pipe Outlet Inlet Weight

Boundary dimension

(L*W*H)

(t/h) (mm) (mm)   (mm) (kg) (mm)
BSQT-F50 1.5 2900 2-40 0.01-0.1 50 10 20 30 60 255*500*700
BSQT-F65 1.5/2.2 2900 2-40 0.02-0.5 65 10 20 30 65 500*345*675
BSQT-F80 3 2900 2-40 0.3-1 80 12 25 48 150 700*570*920
BSQT-F100 5.5 2900 2-40 0.5-2 100 12 25 66 240 800*645*900
BSQT-F120 7.5 2900 2-40 0.5-3 120 12 32 66 250 800*645*900
BSQT-F140 11 2900 2-40 0.5-4 140 12 32 66 275 800*750*1020
BSQT-F200 18.5 2900 2-40 1-10 200 12 38 100 400 900*850*1200



Working Method:

The chili paste grinding machie is based on the relative motion of the stator and rotor with different geometric shapes in high-speed rotation. When machining materials by adjusting the STATOR and rotor gap under its own weight, air pressure and Centrifugal Force, it receives a powerful shearing force, friction, influence, high frequency vibration and other combined forces to effectively crush, disperse, emulsify and mix to obtain ideal product. There are three grinding areas in the crushing room, the first stage is the coarse grinding area, the second stage is the fine grinding area and the third stage is the ultra-fine grinding area. By adjusting the gap between the stator and the rotor, the desired effect of ultra-micro crushing (can also be recycled) .



Features:

Except for the motor part, all contact parts are made of stainless steel, especially the dynamic and static grinding discs are made of reinforced materials, which have good corrosion resistance and wear resistance. In this case, the finished product is pollution-free and safe. The colloid mill has the characteristics of compact design, beautiful appearance, good sealing, stable performance, convenient operation and high production efficiency. It is an ideal equipment for processing fine materials.

The motor and base are separated in the split colloid mill, with good stability, convenient operation, long service life of the motor, avoiding material leakage and burning out of the motor. Labyrinth seal is adopted, which has no wear, corrosion resistance and less faults.

It adopts belt pulley transmission, speed change and acceleration to crush the materials. The vertical colloid mill solves the problem that the small colloid mill cannot work continuously for a long time due to insufficient power and poor sealing. The motor is 220V, which has the advantages of compact overall structure, small volume, light weight, reliable sealing structure and long continuous working time. It is especially suitable for small enterprises and laboratories.



About Capacity:
Colloidal mill type size determines its output? Colloidal mill flow is not constant, different concentration, viscosity of materials, flow changes greatly.
Such as: the same equipment in the processing of viscous paint materials and thin milk fluid, the flow can be more than 10 times.



Industrial 40um Peanut Butter Colloid Mill Chili Paste Grinding Machine 0
