Food Industry Free Fall Vertical Metal Detector For Powder And Granules
BSXR series metal separator / free falling metal detector can remove or separate metal particles that may exist in plastic particles (such as ferrous iron, aluminum, brass, copper, stainless steel, etc.) (even if the metal particles are encapsulated in the product). The metal separator can prevent metal from entering the injection molding machine and reduce the damage to the mold, hot nozzle and valve.
Technical Data:
| Model | Feed diameter | Accuracy | Compressed air | Max capacity(L/h) | Raw material temperature |
Unqualified material discharge time |
||
| (Фmm) | FeΦ | SUSΦ | Other Metal | |||||
| BSXR-3500-50B | 50 | 0.3mm | 0.6mm | 0.3~0.6 mm | 3～5Bar | 2000 | < 80℃ | 0.3～5s |
| BSXR-3500-70B | 70 | 0.7mm | 1.0mm | 0.7~1.0 mm | 3～5Bar | 5000 | < 80℃ | 0.3～5s |
| BSXR-3500-100B | 100 | 0.8mm | 1.2mm | 0.8~1.2 mm | 3～5Bar | 12000 | < 80℃ | 0.3～5s |
| BSXR-3500-120B | 120 | 1.2mm | 1.5mm | 1.2~1.5 mm | 3～5Bar | 16000 | < 80℃ | 0.3～5s |
| BSXR-3500-150B | 150 | 1.5mm | 2.0mm | 1.5~2.0 mm | 3～5Bar | 25000 | < 80℃ | 0.3～5s |
| BSXR-3500-200B | 200 | 1.8mm | 2.2mm | 1.8~~2.2 mm | 3～5Bar | 44000 | < 80℃ | 0.3～5s |
| BSXR-3500-250B | 250 | 2.5mm | 3.8mm | 2.5~~3.8 mm | 3～5Bar | 50000 | < 80℃ | 0.3～5s |
Features:
1. Integrate detection coil, controller and separation device. Simple operation and convenient installation.
2. It can save the loss of materials, because the rejection board quickly rejects unqualified materials.
3. Low installation height, easy for integrity;
4. Testing material performance: dry, good fluidity, not long fiber, non-conductive;
5. Testing material temperature: less than 80℃; if it exceeds 80℃, special components can be selected.
6. The controller can be installed about 10m away from the inspection site.
7. Mainly used for the detection of (8mm) loose granular materials. These materials fall into the detection coil under the action of gravity.
8. This machine is suitable for plastic, food, chemical and other industries.
Advantages:
1. The shell material is made of SUS304 and the parts that are in direct contact with the product.
2. High sensitivity to all metals; effective shock and sound insulation, special structure design;
3. A variety of calibers can be selected to meet various practical applications.
4. Avoid moldy due to product backlog and blockage.
5. Simple operation, space saving, and compact design ensures quick installation.
6. The patented metal separator can ensure safety even when processing a large amount of grinding materials (dust) and can be operated repeatedly.
