Product Details:
|
| Product Name: | Pharma Metal Detector | Other Name: | Metal Separator Machine |
|---|---|---|---|
| Application: | Foodstuff Industry | Material: | Stainless Steel 304/316 |
| Size(mm): | 1330×750×1100(L×W×H) | Weight: | 180kg |
| Function: | Detecting Metal From Raw Materials | ||
| High Light: | got automatic food processing machine,waterproof automatic food processing machine,waterproof food metal detector |
||
Foodstuff Industry Got ISO Automatic Metal Separator Machine
Technical Data:
| Model | XR-980 | ||||||||
| Type | standard machine | Non-standard machine (special specification) | |||||||
| Detection channel width(mm) | 400 | Non-standard machine (special specification) | |||||||
| Detecting channel height(mm)(≤200) | 100 | 120 | 150 | 200 | 250 | 300 | 350 | 400 | |
| Calibration detection sensitivity | Iron ball diameter(Φmm) | ≥0.6 | ≥0.8 | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 |
| Diameter of non-ferrous metals such as copper and aluminum(Φmm) | ≥1.2 | ≥1.2 | ≥1.5 | ≥1.5 | ≥2.5 | ≥3.0 | ≥4.0 | ≥4.5 | |
| 304 stainless steel ball diameter(Φmm) | ≥1.2 | ≥1.5 | ≥2.0 | ≥3.0 | ≥3.5 | ≥3.5 | ≥4.0 | ≥4.5 | |
| Type of alarm | Detect metal foreign matter automatically stop running, buzzer alarm or remove | ||||||||
| Material | The whole frame is made of 304 mirror stainless steel | ||||||||
| Size(mm) | 1330×750×1100(L×W×H) | ||||||||
| Weight | About 180KG | ||||||||
| Note: the above sensitivity parameters are the test results of the air machine without environmental interference,the actual application will be slightly different due to the interference of the use environment and the components of the detected object! | |||||||||
Features:
1) Made of 304 stainless steel, durable and nice appearance, conveyor and pallet assembly used in the U.S. standards of white non-toxic materials.
2) Digital machine, memory function for registering various products(Max: over 12 items)
3) adopt the combine technology of double signal and detection circuit, LCD display, with Chinese and English menu, easy operation.
4)Adopt Germany professional detection technology with balanced principle, more reliable, better performance.Dual-channel and frequency detecting ferrous, non-ferrous and stainless steel
5) DSP and MCU combination of the detection signal for data sampling and data processing, improve the detection results.
6)a new circuit design, high sensitivity, mature phase adjustment technology, can adjust the products automatically, inhibit the products effect effectively.
7)Able to detect iron, stainless steel, copper, aluminum and other non-ferrous metals and other materials.
8)With the learning function of automatic identification, overcome the effect of products materials efficiently, strong anti-interference and shock proof.
9)Support 24 hours non-stop working.
10) fairly good waterproof ability, apply to high temperature, low temperature, damp, dry, dust, dew and other poor work environment.
Application:
This belt typr metal separator machine is mainly used to detect metal impurities and metal foreign matter in food, bread, steamed bread, dumplings, biscuits and other products, as well as pharmaceuticals, toys, clothing, footwear, chemicals, leather and other products or raw materials in the production process of metal impurities, knitting and other industries. For example, ferrous and non-ferromagnetic metal items (which can detect non-ferrous metals such as iron, copper, aluminum, stainless steel, etc.) can improve the safety factor and product quality of the product.
