Product Details:
|
| Product Name: | Automatic Labeling Machine For Round Bottles | Other Name: | 10ml Bottle Labeling Machine |
|---|---|---|---|
| Material Size: | External Diameter φ 20- φ 100 Mm；high 30-200 Mm200mm | Applicable Label Inner Diameter: | φ76mm |
| Applicable Label Roll Outer Diameter: | Maximum Φ 250mm | Application: | Round Bottle |
| Advantage: | Easy To Operate | ||
| High Light: | 10ml Bottle Automatic Labeling Machine,0.5mm Accuracy Automatic Labeling Machine,ce iso tabletop automatic labeling machine |
||
±0.5mm Labeling Accuracy 10 To 40 Pieces Per Min 10ml Bottle Labeling Machine
Introduction:10ml Bottle Labeling Machine
The glass bottle labeling machine is suitable for different sizes of self-adhesive labels or self-adhesive film pasted on a variety of round bottles, cans, barrels for self-adhesive labeling, with high precision and fast speed. Suitable for PET bottle, plastic bottle, glass bottle, metal bottle, round bottle, etc.
Application:10ml Bottle Labeling Machine
1. Self adhesive labels for round bottles, cans, cylinders, etc.
2. It is suitable for labeling round bottles such as PET bottles, plastic bottles, glass bottles and metal bottles.
3. It is widely used in cosmetics, beverages, food, medicine and other industries, greatly improving the production efficiency and labeling quality
Technical Data:10ml Bottle Labeling Machine
|
Model/Technical Parameters
|
XT-50
|
|
Labeling speed
|
10-40 pieces / min (related to material and label size)
|
|
Labeling accuracy
|
±0.5mm(excluding material and label size)
|
|
Material size
|
external diameter φ 20- φ 100 mm；
high 30-200 mm200mm
|
|
Applicable label inner diameter
|
φ76mm
|
|
Applicable label roll outer diameter
|
maximum Φ 250mm
|
|
Using electricity
|
AC220V 50Hz/60Hz 120W
|
|
Overall dimensions
|
(L)650 (W)350 (H)550mm
|
Features:10ml Bottle Labeling Machine
1. Desktop design, simple structure, compact appearance, powerful function.
2. The use of anodized aluminum alloy support and advanced computer white box, beautiful and generous.
3. Using advanced electric eye, it has high detection sensitivity for target and label.
4. Wide range of application, can be used for 20-100 mm labeling roller.
5. The precision of labeling is high, and the head and tail joint deviation is 0.5mm.
6. The ingenious extrusion device is used for feeding, and only the workpiece needs to be placed to automatically complete the labeling.
7. It is convenient to switch different parts for labeling by adjusting the clamping position.
8. Adopt synchronous belt traction, greatly improve the mechanical stability.
